Semi Automatic Paste Filling Machine

Semi Automatic Paste Filling Machine


Pneumatic twin‑head piston filler with hopper. Select a cylinder module from 10–100 ml up to 1000–5000 ml to suit your dose.


View Specs Configure & Quote

  • Two filling heads
  • Multiple volume modules
  • Anti‑drip nozzles
  • Manual/Auto
Twin-head pneumatic piston paste filler with hopper

Key Features

Two filling heads

Higher output with compact footprint.

Multiple volume modules

10–100 / 10–200 / 30–300 / 50–500 / 100–1000 / 500–2500 / 1000–5000 ml.

Anti‑drip nozzles

Clean fills for viscous products.

Manual/Auto

Foot pedal or timed cycle.

Air‑powered

0.4–0.6 MPa; low electrical demand.

Hopper feed

Gravity or pump‑assisted supply.

Technical Specifications

Filling & Control

Nozzles
2
Volume modules
10–100 to 1000–5000 ml
Accuracy
≈±0.5% (ref.)
Modes
Manual & Auto
Drive
Pneumatic + low electric
Nozzle type
Anti‑drip

Utilities & Dimensions

Voltage
110/220 V (controls)
Air
0.4–0.6 MPa
Hopper
Stainless; optional heating/mixer
Materials
Stainless contact parts
Footprint
Benchtop/stand mounted
Integration
Feeds to conveyors

Performance depends on product, container, and setup. Ask us for a timed trial.

Typical Applications

Food

Honey, sauces, creams.

Cosmetics

Lotions, gels.

Household

Detergents, pastes.

What’s Included

  • Twin‑head filler base
  • Hopper
  • Foot pedal & fittings
  • User manual

Configure Your Machine


Tell us about your application. We’ll confirm compatibility and quote the best configuration.

  • Product viscosity and solids
  • Target volume and cycle time
  • Nozzle size and neck finish
  • Air supply capacity

Enquire about this machine now
